Electronics Devices and Circuit Laboratory

Major Equipment Available

  1. Cathode Ray Oscilloscope, 20 MHz
  2. Audio Signal Generators.0 to 1MHz
  3. Function Generator
  4. Digital Storage Oscilloscopes 40 Mhz
  5. DPSK Kits
  6. QPSK
  7. Optical Fiber Kits
  8. Microwave Test Bench
  9. Micro Strip Kits (MIC Kits)
  10. TDM Kits - 2 Nos.
Digital Electronics and Circuit Laboratory

Major Equipment Available

  1. Dual Trace Oscilloscope 20/30MHz
  2. Signal / Function Generators
  3. UDPT Programmer / Intelligent Universal Programmer
  4. 8031 Simulator - 1 set
Communication Laboratory

Major Equipment Available

  1. Cathode Ray Oscilloscope, 20 MHz
  2. Audio Signal Generators.0 to 1MHz
  3. Function Generator
  4. Digital Storage Oscilloscopes 40 MHz
Advanced Communication Laboratory

Major Equipment Available

  1. Cathode Ray Oscilloscope, 20 MHz
  2. Audio Signal Generators.0 to 1MHz
  3. Function Generator
  4. Digital Storage Oscilloscopes 40 Mhz
  5. DPSK Kits
  6. QPSK
  7. Optical Fiber Kits
  8. Microwave Test Bench- 3 Sets
  9. Micro Strip Kits (MIC Kits)
  10. TDM Kits - 2 Nos.
  11. Dual Trace Oscilloscope 20/30MHz
  12. Signal / Function Generators
Linear Integrated Circuits Laboratory

Major Equipment Available

  1. Cathode Ray Oscilloscope, 20 MHz
  2. Audio Signal Generators.0 to 1MHz
  3. Function Generator
  4. Digital Storage Oscilloscopes 40 Mhz
  5. Function Generators
  6. UDPT Programmer / Intelligent Universal Programmer
  7. 8031 Simulator - 1 set
  8. Digital Storage Oscilloscope 40 Mhz
Embedded Systems Laboratory

Major Equipment Available

  1. Dual Trace Oscilloscope 20/30MHz
  2. ESA MC/ MP Kits
  3. Computers - 25 Nos
  4. IOT Evaluation Board, Ardino Uno
Digitial Signal Processing Laboratory

Major Equipment Available

  1. Dual Trace Oscilloscope 20/30MHz
  2. DSP - TMS320 5416,5510,67xx
  3. MSP TMS430 Kit
  4. UPS 5 KVA - 1 No.
  5. UPS - 3 KVA - 2 Nos.
IOT and Networking Labboratory

Major Equipment Available

  1. IOT Evaluation Board
  2. Raspberry Pi
  3. Computers- 20 Nos
VLSI Laboratory

Major Equipment Available

  1. Microwind Software 3.1
  2. Cadence Software
PG Computer Centre

Major Equipment Available

  1. DELL Optiflex 755 Core 2 Duo E7200 & HP Pro 3090 Computers -30 Nos.
  2. T-CAD Synopsis Tool Software
  3. Arm Processors - 5 Nos.
  4. FPGA Boards - 2 Nos.
  5. LabView software.
  6. UPS 5 KVA - 1 Nos.
  7. UPS - 3 KVA - 3 Nos.
M10x Center / Project Laboratory

Major Equipment Available

  1. HP Pro 3090 Computers -25 Nos.
  2. Mission 10X kits - 20 Nos.
  3. Intel Atom Kits - 10 Nos.
  4. UPS - 3 KVA - 3 Nos.
Wireless Communication Laboratory

Major Equipment Available

  1. Wave guru SDR kits - 5
  2. Different RF SMA cables
  3. 300-2500 MHz splitters
  4. FM & 2500Mhzantennas
  5. Attenuators
E - Class Room

Major Equipment Available

  1. Dell 3046 Computers -36 Nos.
  2. UPS - 5 KVA - 4 Nos.
  3. Equipped with smart board and audio system accessories.
  4. Software: Scilab, Virtual lab, Octave, Python, CCS studio.
